Description

• Capacity: 1500 VA / 900 W
• Type: Line-Interactive
• Input:
• Nominal Voltage: 230 VAC
• Accepted Voltage Range: 162 ~ 290 VAC
• Frequency Range: 50Hz / 60Hz (Auto Sensing)
• Output:
• Nominal Voltage: 230 VAC
• Accepted Voltage Range: 207 ~ 253 VAC
• Frequency Range (Batt. Mode): 50 Hz / 60Hz ± 1%
• Power Factor: 0.6 @ nominal voltage (100% load)
• Waveform (Batt. Mode): Simulated Sinewave
• Transfer Time: Typical 4 ms
• Overload Protection: Circuit breaker
• Line mode overload: > (110% ±10%) fault after alarm 1 min; > (120% ±10%) fault immediately
• Battery mode overload: > (110% ±10%) fault after alarm 1 min; > (120% ±10%) fault immediately
• Indicators:
• Type: LED & Alarm
• Indicators Displayed: Load Capacity, Load & Battery level, AC mode, Battery mode, Fault indicators
• Protection:
• Outlets Type: 4 x Schuko Battery Backup
• Additional Protection: 2 x RJ11/45 (IN/OUT) for modem/phone/LAN surge protection
• Full Protection: Overload, Over voltage, Short Circuit, Over discharge and Over charge
• Environment:
• Noise Level: Less than 40dB
• Humidity: 0-90 % (non-condensing)
• Temperature: 0-40ºC
• Battery:
• Battery Type & Number: 2 x GP09122L (PN: BTVACGUEBTC2LBT01B)
• Typical Recharge Time: 6 hours up to 90% capacity
• Running Time on Battery (minutes): 25% Load – 25 min, 50% Load – 8 min, 75% Load – 3 min, 100% Load – 1 min
• Product Dimensions: 298 x 148 x 178 mm
• Product Weight: 9.1 kg
• Power Cord Length: 1.2 m
