Description

•Eliminate weak signal areas with whole home WiFi coverage.2.4 GHz (300 Mbps) and 5 GHz (867 Mbps) dual-band WiFi connection ensures more stable wireless experience.(Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.)•Creates a Mesh network by connecting to a OneMesh router for seamless whole-home coverage.(Smart Roaming is designed for devices that support the 802.11k/v standard.)•Adaptive Path Selection – connects to the fastest connection path to the router automatically and runs at top-speed.•High Speed Mode – maximizes speed by using one WiFi band as dedicated backhaul, ideal for HD streaming and gaming.•AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability.•Smart Signal Indicator – helps to fi­nd the best location for optimal Wi-Fi coverage by showing the signal strength.•Push the WPS button to easily connect to the router and you can uniformly manage from the Tether app or Web UI.•Works with any Wi-Fi router or wireless access point (the product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.)

HARDWARE FEATURESInterface : 1 x 10/100M Ethernet Port (RJ45)Button: WPS Button, Reset ButtonPower Consumption : 9.5W（max power consumption）Dimensions ( W x D x H ) (89×35.0×124.1 mm)Antenna : 2 External AntennasWIRELESS FEATURESWireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHzFrequency : 2.4GHz & 5GHz(11ac)Signal Rate : 5 GHz:Up to 867 Mbps, 2.4 GHz:Up to 300 MpbsWireless Functions : Enable/Disable Wireless Radio, Wireless StatisticsWireless Security : 64/128-bit WEP, WPA/WPA-PSK2/WPA2-PSK2 encryptionsTransmission Power : 2.4 GHz ≤20dBm, 5 GHz ≤30dBm
